494 3-Piece Spout Assembly

494 3 Piece Spout Assembly

Parts

Sch. ID Product Image Kooima Ag # Title Replaces OEM # Price Quantity
1 K0682520 Hi-Arch Spout Kit 682520 $3,525.00
1a K0682520BK Spout Assembly Bolt Kit $14.00
2 K0682530 Lower Spout Section 0682533, 0682530 $1,490.00
3 K0786470 Middle Spout Section 786473 $325.00
4 K0786530 Upper Spout Section 786531 $445.00
5 K0682380 Lower Rear Spout Liner 0682382 $129.00
5a K0682380BK Bolt Kit for K0682380 and K0786770 $6.90
6 K0766462 Middle Rear Spout Liner 0766463 $91.00
6a K0766462BK Bolt Kit for K0766462 $8.75
7 K0786730 Top Rear Spout Liner 786731 $98.00
